DC5V 12V Full Color 12mm Square Pixel LED Ws2811 Ws2812b


Basic Info.

Model NO.
5050
Power Wattage
18W, 22W, 24W, 36W
Length
5 Meter
LED Chip
Epistar
Warranty
2 Years
Width
10mm
Transport Package
5m/Roll
Specification
CE, RoHS, FCC, UL
Trademark
Monssen
Origin
Guangdong, Shenzhen
HS Code
94054090
Production Capacity
100000 Meters

Product Description

DC5V 12V Full Color 12mm Square Pixel LED Ws2811 Ws2812b

LED Strip light Specification:

CE/RoHS certificates.
12V/24V DC.
3528 or 5050 led components.
Waterproof or non-waterproof are both availble.
No remark from customer,we will send DC12V basicly led strip for shippment
Features:
1. Every 3LEDs can be cut at marked intervals and can be rejoined. The normal packing is 5meters/reel.
2. Both waterproof (IP68 or IP65) or non-waterproof are available
3. Colors: Red, yellow, blue, green, white, warm white and RGB color are both available.
4. Low Power Consumption. These strips are extremely energy-efficient,
This low-voltage Strip produces little heat, very safe to use and easy to install, lifespan of over 50,000 hours, with CE& ROHS certificate that strictly ensures that no toxic materials were used in its manufacture.
5. The Flexible Strips have a 120° wide-angle beam that ensures they light evenly and do not cast shadows on surfaces and boasts a desirable seamless glow.
6. Easy installation. This LED tape comes with a 3M adhesive backing which allows easy mounting virtually anywhere. Because they can be cut, they fit well into installations and are perfect for use in display cases.

Close Picture for rgb led strip kits,include 5meter/roll rgb led strip wateprroof , ir 44key remote controller,dc12v 5a adaptor.with blister package


Application for led strip
1) Building (architecture or home) decoration, kitchen-cabinet lighting, under-cabinet lighting, and bathroom lighting,
2) Car decoration, coves, valences, doorways and other hard-to-light nooks and crannies.
3) Amusement park and theater lighting
4) Emergency hallway lighting
5) Shopping mall, restaurant, hotel, meeting room and advertisement signs backlighting


LED Strip List:

Part Numbe
ColorLED ParameterWattageSizePowerOEM/Customize?
3528-30LEDR/G/B/Y/W/WWSMD3528/30LED2.4W/M8*1000MMDC12V/DC24VYES
3528-60LEDR/G/B/Y/W/WWSMD3528/60LED4.8W/M8*1000MMDC12V/DC24VYES
3528-120LEDR/G/B/Y/W/WWSMD3528/120LED9.6W/M8*1000MMDC12V/DC24VYES
5050-30LEDR/G/B/Y/W/WW/RGBSMD5050/30LED7.2W/M10*1000MMDC12V/DC24VYES
5050-60LEDR/G/B/Y/W/WW/RGBSMD5050/60LED14.4W/M10*1000MMDC12V/DC24VYES

  More series led strip

5630-60           LED
whiteSMD5630/60LED18W/M8*1000MMDC12V/DC24VYES
2835-60      LEDR/G/B/Y/W/WWSMD2835/60LED12W/M8*1000MMDC12V/DC24VYES
2835-120  LEDR/G/B/Y/W/WWSMD2835/120LED24W/M8*1000MMDC12V/DC24VYES
2835-240  LEDR/G/B/Y/W/WWSMD2835/240LED36W/M12*1000MMDC12V/DC24VYES
3014-60  LEDR/G/B/Y/W/WWSMD3014/60LED12W/M10*1000MMDC12V/DC24VYES
3014-120   LEDR/G/B/Y/W/WWSMD3014/120LED24W/M10*1000MMDC12V/DC24VYES



More accessories for led strip light:



Digital RGB led strip (WS2011/WS2812B) Specification/Items:


Business model

Manufacture

Item Model

MS-WS2812B-60

LED Quantity

60PCS/M,300PCS/Reel

IC Type

WS2812B (IC Built in LED)

Wattage

18W/M

Pixel/m

60pixel/m,300pixel/reel

PCB Width

10mm

Length/Reel

5M

Working Voltage

DC5V

Package

Anti-Static Bag

Light Color

Multi-Color, digital RGB,Every LED individual Control

IP Grade

IP20:Non waterproof
IP65:Soft glue waterproof
IP67:Soft tube waterproof
IP68:Soft tube+glue waterproof

Glue Type

Expoy:Non-anti-UV,Stay clean for short time,smell
Silicone:Anti-UV,Stay clean,soft,smell-less
PU: Anti-UV,Stay clean,soft,smell-less

PCB Color

White ,Black

Certification

CE RoHS

Cut size

DC5V (every LED per cut),
DC12V (every 3LED per cut)

Installation

IP20 with 3M Adhesive tape on the back of PCB
IP65 with 3M Adhesive tape on the back of PCB
IP67 with plastic clip and screw
IP68 with plastic clip and screw



Many other types IC for choose





Addressable LED Strip with ,IC WS2811 WS2812,Individual Pixel Control
AMS-WS2812B-3030pcs SMD5050/M9W/MDC5V30 Pixel/MWS2812BDream Color RGBIP20 IP65 IP67 IP68
BMS -WS2811-3030pcs SMD5050/M7.2W/MDC12V10 Pixel/MWS2811Dream Color RGBIP20 IP65 IP67
CMS-WS2811-4848pcs SMD5050/M11.5W/MDC12V16 Pixel/MWS2811Dream Color RGBIP20 IP65 IP67
DMS-WS2811-6060pcs SMD5050/M14.4W/MDC12V20 Pixel/MWS2811Dream Color RGBIP20 IP65 IP67
EMS-WS2812B-6060pcs SMD5050/M18W/MDC5V60 Pixel/MWS2812BDream Color RGBIP20 IP65 IP67
FMS-WS2812B-144144pcs SMD5050/M43.2W/MDC5V144 Pixel/MWS2812BDream Color RGB
