F8 Ws2011 Full Color 12mm Thin Digital Dream Color LED Pixel
Basic Info.
Model NO.
F8
Power Wattage
18W,22W,24W,36W
LED Chip
Epistar
Length
5 Meter
LED Qty
60PCS
Transport Package
5m/Roll
Specification
CE, RoHS, FCC, UL
Trademark
Monssen
Origin
Guangdong, Shenzhen
HS Code
94054090
Production Capacity
100000 Meters
Product Description
5050SMD 12V RGB 300leds Indoor Digital Decorate LED Strip Light
Specifications:
1. 5mm, 8mm, 12mm dip rgb led
2. High quality, good price
3. Eco-friendly, energy-saving
4. 3 years warranty
5. Epistar chip
Futures:
LEDs: SMD5050*1pcs
Power: DC5V. 0.3W
View angle : ≥160°
Color : White,Cold White ,Warm White,Red,Green,Blue,Yellow,Full Color
Color temperature : White (5000~7000K), Cold white ( 11000~15000K)
Wire output : Gray color ( + ), White color ( - )
IP rank : IP67 waterproof
Environment conditions : -20°C- +60°C
Store conditions : -30°C- +60°C
LED Strip List:
Digital RGB led strip (WS2011/WS2812B) Specification/Items:
Low voltage DC input
Do not hot-line work
expansion screws should be used outdoor installation,so as not to fall off
Keep away from heat
The series less than 4m between lamps
Recommended power supply is more reasonable, which is generally 70-80% of rated power load, in order to avoid long-term high load power supply to damange the power supply and power
F8 WS2011 full color 12mm thin digital dream color LED pixel
Why choose us?
1. We are Professional Led Lighting manufacturer in Shenzhen, China
2. Capacity: 2.5million pcs of storage items produced and exported annually
3. New items every quarter and quick response
4. Delivery: Punctual delivery for more than 95% orders
5. Approved by CE & RoHS.
F8 WS2011 full color 12mm thin digital dream color LED pixel
Our Services:
1. Inquiry response: Your enquiries will be replied in 24 hours.
2. Delivery time: Your shipment will be loaded in 3~15 days, depends on quantity.
3. Payment term: T/T,L/C,D/P,D/A,Western union, Paypal.
4. ODM order: Customized design is available.
Specifications:
1. 5mm, 8mm, 12mm dip rgb led
2. High quality, good price
3. Eco-friendly, energy-saving
4. 3 years warranty
5. Epistar chip
Futures:
LEDs: SMD5050*1pcs
Power: DC5V. 0.3W
View angle : ≥160°
Color : White,Cold White ,Warm White,Red,Green,Blue,Yellow,Full Color
Color temperature : White (5000~7000K), Cold white ( 11000~15000K)
Wire output : Gray color ( + ), White color ( - )
IP rank : IP67 waterproof
Environment conditions : -20°C- +60°C
Store conditions : -30°C- +60°C
LED Strip List:
Part Numbe | Color | LED Parameter | Wattage | Size | Power | OEM/Customize? |
3528-30LED | R/G/B/Y/W/WW | SMD3528/30LED | 2.4W/M | 8*1000MM | DC12V/DC24V | YES |
3528-60LED | R/G/B/Y/W/WW | SMD3528/60LED | 4.8W/M | 8*1000MM | DC12V/DC24V | YES |
3528-120LED | R/G/B/Y/W/WW | SMD3528/120LED | 9.6W/M | 8*1000MM | DC12V/DC24V | YES |
5050-30LED | R/G/B/Y/W/WW/RGB | SMD5050/30LED | 7.2W/M | 10*1000MM | DC12V/DC24V | YES |
5050-60LED | R/G/B/Y/W/WW/RGB | SMD5050/60LED | 14.4W/M | 10*1000MM | DC12V/DC24V | YES |
5630-60 LED | white | SMD5630/60LED | 18W/M | 8*1000MM | DC12V/DC24V | YES |
2835-60 LED | R/G/B/Y/W/WW | SMD2835/60LED | 12W/M | 8*1000MM | DC12V/DC24V | YES |
2835-120 LED | R/G/B/Y/W/WW | SMD2835/120LED | 24W/M | 8*1000MM | DC12V/DC24V | YES |
2835-240 LED | R/G/B/Y/W/WW | SMD2835/240LED | 36W/M | 12*1000MM | DC12V/DC24V | YES |
3014-60 LED | R/G/B/Y/W/WW | SMD3014/60LED | 12W/M | 10*1000MM | DC12V/DC24V | YES |
3014-120 LED | R/G/B/Y/W/WW | SMD3014/120LED | 24W/M | 10*1000MM | DC12V/DC24V | YES |
Digital RGB led strip (WS2011/WS2812B) Specification/Items:
Business model | Manufacture |
Item Model | MS-WS2812B-60 |
LED Quantity | 60PCS/M,300PCS/Reel |
IC Type | WS2812B (IC Built in LED) |
Wattage | 18W/M |
Pixel/m | 60pixel/m,300pixel/reel |
PCB Width | 10mm |
Length/Reel | 5M |
Working Voltage | DC5V |
Package | Anti-Static Bag |
Light Color | Multi-Color, digital RGB,Every LED individual Control |
IP Grade | IP20:Non waterproof IP65:Soft glue waterproof IP67:Soft tube waterproof IP68:Soft tube+glue waterproof |
Glue Type | Expoy:Non-anti-UV,Stay clean for short time,smell Silicone:Anti-UV,Stay clean,soft,smell-less PU: Anti-UV,Stay clean,soft,smell-less |
PCB Color | White ,Black |
Certification | CE RoHS |
Cut size | DC5V (every LED per cut), DC12V (every 3LED per cut) |
Installation | IP20 with 3M Adhesive tape on the back of PCB IP65 with 3M Adhesive tape on the back of PCB IP67 with plastic clip and screw IP68 with plastic clip and screw |
Many other types IC for choose |
Addressable LED Strip with ,IC WS2811 WS2812,Individual Pixel Control | ||||||||
A | MS-WS2812B-30 | 30pcs SMD5050/M | 9W/M | DC5V | 30 Pixel/M | WS2812B | Dream Color RGB | IP20 IP65 IP67 IP68 |
B | MS -WS2811-30 | 30pcs SMD5050/M | 7.2W/M | DC12V | 10 Pixel/M | WS2811 | Dream Color RGB | IP20 IP65 IP67 |
C | MS-WS2811-48 | 48pcs SMD5050/M | 11.5W/M | DC12V | 16 Pixel/M | WS2811 | Dream Color RGB | IP20 IP65 IP67 |
D | MS-WS2811-60 | 60pcs SMD5050/M | 14.4W/M | DC12V | 20 Pixel/M | WS2811 | Dream Color RGB | IP20 IP65 IP67 |
E | MS-WS2812B-60 | 60pcs SMD5050/M | 18W/M | DC5V | 60 Pixel/M | WS2812B | Dream Color RGB | IP20 IP65 IP67 |
F | MS-WS2812B-144 | 144pcs SMD5050/M | 43.2W/M | DC5V | 144 Pixel/M | WS2812B | Dream Color RGB |
Low voltage DC input
Do not hot-line work
expansion screws should be used outdoor installation,so as not to fall off
Keep away from heat
The series less than 4m between lamps
Recommended power supply is more reasonable, which is generally 70-80% of rated power load, in order to avoid long-term high load power supply to damange the power supply and power
